Page #21 background image
Reproduction forbidden without Fibocom Wireless Inc. written authorization - All Rights Reserved
FIBOCOM L610 Series Hardware Guide Page 21 of 59
Pin
Pin Name
I/O
Level
Reset
Value
Description
VILmax=0.6V
VIHmin=1.2V
VIHmax=2.0V
43
ADC2
I
-
-
Analog to digital converter interface 2
Connect 1k in series when in use; left
floating when not in use
44
ADC1
I
-
-
Analog to digital converter interface 1
Connect 1k in series when in use; left
floating when not in use
45
ADC0
I
-
-
Analog to digital converter interface 0
Connect 1k in series when in use; left
floating when not in use
46
GND
G
-
-
Ground
47
ANT_GNSS
-
-
-
GNSS
48
GND
G
-
-
Ground
49
ANT_MAIN
I/O
-
-
Main antenna
50
GND
G
-
-
Ground
51
GND
G
-
-
Ground
52
GND
G
-
-
Ground
53
GND
G
-
-
Ground
54
GND
G
-
-
Ground
55
NC
-
-
-
NC
56
GND
G
-
-
Ground
57
VBAT_RF
PI
Vmax=4.3V
Vmin=3.4V
Vnorm=3.8V
-
RF power input (3.4V-4.3V)
58
VBAT_RF
PI
Vmax=4.3V
Vmin=3.4V
Vnorm=3.8V
-
RF power input (3.4V-4.3V)
59
VBAT_BB
PI
Vmax=4.3V
Vmin=3.4V
Vnorm=3.8V
-
Baseband power input (3.4V-4.3V)
60
VBAT_BB
PI
Vmax=4.3V
Vmin=3.4V
Vnorm=3.8V
-
Baseband power input (3.4V-4.3V)
