FIBOCOM L610 Series Hardware Guide Page 22 of 59
Pin
Pin Name
I/O
Level
Reset
Value
Description
61
STATUS
O
VOHmin=1.35V
VOLmax=0.45V
L
Reserved
Left floating when not in use
62
RI
O
VOLmax=0.45V
VOHmin=1.35V
L
Module output ring indicator
Left floating when not in use
63
DCD
O
VOLmax=0.45V
VOHmin=1.35V
L
Module output carrier detection
Left floating when not in use
64
RTS
I
VOLmax=0.45V
VOHmin=1.35V
L
DTE request to send data
Left floating when not in use
65
CTS
O
VILmin=-0.3V
VILmax=0.6V
VIHmin=1.2V
VIHmax=2.0V
L
Module clear to send
Left floating when not in use
66
DTR
I
VILmin=-0.3V
VILmax=0.6V
VIHmin=1.2V
VIHmax=2.0V
L
DTE ready
Left floating when not in use
67
TXD
O
VOLmax=0.45V
VOHmin=1.35V
-
Module Transmit data
Left floating when not in use
68
RXD
I
VILmin=-0.3V
VILmax=0.6V
VIHmin=1.2V
VIHmax=2.0V
-
Module Receive data
Left floating when not in use
69
USB_DP
I/O
-
-
USB signal DP
Left floating when not in use
70
USB_DM
I/O
-
-
USB signal DM
71
USB_VBUS
PI
Vmax=5.25V
Vnorm=5.0V
Vmin=3.4V
-
USB plug detection
Left floating when not in use
72
GND
G
-
-
Ground
73
SPK_P
O
-
-
SPK_P
Left floating when not in use
74
SPK_N
O
-
-
SPK_N
Left floating when not in use
