Light
Description
LON-RX LED
On normal operation of FS-QS-1011-XXXX, the RX LED will flash when a message is received
on the Lon port of the QuickServer.
LON-SRV LED
(next to Lon port)
The LON-SRV LED will flash if the FS-QS-1011-XXXX is configured for implicit addressing and
not commissioned. LED will be off if the FS-QS-1011-XXXX is configured for implicit
addressing and commissioned or if it is configured for explicit addressing.
LED 7
Not used
LED 8
Not used
Appendix D.4. QuickServer FS-QS-101X DCC
Driver
Code
BACnet/IP – BACnet MS/TP
0285
BACnet/IP – LonWorks
0131
JCI Metasys N2 – LonWorks
0097
JCI Metasys N2– BACnet MS/TP
0309
JCI Metasys N2– BACnet/IP
0122
Modbus RTU – BACnet MS/TP
0367
Modbus RTU – BACnet/IP
0104
Modbus RTU – JCI Metasys N2
0038
Modbus RTU – LonWorks
0085
Modbus TCP – BACnet/IP
0237
Modbus TCP – LonWorks
0154
Modbus TCP – BACnet MS/TP
0419
Modbus TCP – JCI Metasys N2
0117
SNMP – BACnet/IP
0333
SNMP – LonWorks
0337
SNMP – JCI Metasys N2
0150
Add BACnet MS/TP - LonWorks
0345
Appendix D.5. Compliance with UL Regulations
For UL compliance, the following instructions must be met when operating the QuickServer.
 The units shall be powered by listed LPS or Class 2 power supply suited to the expected operating
temperature range.
 The interconnecting power connector and power cable shall:
 Comply with local electrical code.
 Be suited to the expected operating temperature range.
 Meet the current and voltage rating for the QuickServer/Net
 Furthermore, the interconnecting power cable shall:
 Be of length not exceeding 3.05m (118.3”)
 Be constructed of materials rated VW-1 or FT-1 or better.
