Appendix D.7. Baud DIP Switch Settings
Please refer to Section 4.1.1 and Section 4.1.2 for Baud Rate supporting Ports
4
Auto-baud is only supported for BACnet MS/TP
Baud
B0
B1
B2
B3
Auto
4
Off
Off
Off
Off
110
On
Off
Off
Off
300
Off
On
Off
Off
600
On
On
Off
Off
1200
Off
Off
On
Off
2400
On
Off
On
Off
4800
Off
On
On
Off
9600
On
On
On
Off
19200
Off
Off
Off
On
20833
On
Off
Off
On
28800
Off
On
Off
On
38400
On
On
Off
On
57600
Off
Off
On
On
76800
On
Off
On
On
115200
Off
On
On
On
