QuickServer Start-up Guide Page 4 of 43
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: support@fieldserver.com
1 EQUIPMENT SET-UP
QuickServer is a high performance, cost effective Building and Industrial Automation multi-protocol gateway
providing protocol translation between serial, Ethernet, and LonWorks devices and networks.
2 SUPPLIED EQUIPMENT
QuickServer Gateway.
Preloaded with the two selected drivers (on the FS-QS-1X11 and FS-QS-12X1 one of those drivers is
LonWorks). A sample configuration file is also pre-loaded onto the QuickServer.
All instruction manuals, driver manuals, configuration manuals and support utilities are available on the USB
drive provided in the optional accessory kit, or on-line at www.fieldserver.com/QS_Support/
Accessory kit (Optional) (Part # FS-8915-36-QS) including:
7-ft CAT5 cable with RJ45 connectors at both ends
Power Supply -110/220V (p/n 69196)
DIN Rail mounting bracket
Screwdriver for connecting to terminals
USB Flash drive loaded with:
o QuickServer Start-up Guide
o FieldServer Configuration Manual
o FieldServer Utilities Manual
o All FieldServer Driver Manuals
o Support Utilities
o Any additional folders related to special files configured for a specific QuickServer
o Additional components as required - See Driver Manual Supplement for details
2.1 BTL Mark – BACnet Testing Laboratory
The BTL Mark on the ProtoNode RER is a symbol that indicates to a consumer that a
product has passed a series of rigorous tests conducted by an independent laboratory
which verifies that the product correctly implements the BACnet features claimed in the
listing. The mark is a symbol of a high-quality BACnet product. For more information about
the BACnet Testing Laboratory go to: http://www.bacnetinternational.net/btl/
2.2 LonMark Certification
LonWorks is a registered trademark of Echelon Corporation
Metasys is a registered trademark of Johnson Controls Inc.
BACnet is a registered trademark of ASHRAE
LonMark International is the recognized authority for certification, education, and
promotion of interoperability standards for the benefit of manufacturers, integrators and
end users. LonMark International has developed extensive product certification
standards and tests to provide the integrator and user with confidence that products
from multiple manufacturers utilizing LonMark devices will work together. FieldServer
Technologies, manufacturer of the QuickServer has more LonMark Certified gateways
than any other gateway manufacturer.
