3.3 Specifications
2
FS-QS-1010-XXXX & FS-QS-12X0-XXXX
3
FS-QS-1011-XXXX & FS-QS-12X1-XXXX
Available Ports
One 6-pin Phoenix connector, one RS-
485 +/- ground port, power +/- frame
ground port
One 3-pin RS-485 Phoenix connector,
one RS-485 +/- ground port
One Ethernet-10/100 port
One 6-pin Phoenix connector, one RS-485 (or RS-232
or RS-422) +/- ground port, power +/- frame ground
port
2-pin FTT-10 LonWorks port
One Ethernet-10/100 port
Power
Requirements
Input Voltage: 9-30VDC or 12-24VAC
Input Power Frequency 50/60 Hz.
Power Rating: 2.5 Watts
Current draw @ 12V, 150 mA
Input Voltage: 9-30VDC or 12-24VAC
Input Power Frequency 50/60 Hz.
Power Rating: 2.5 Watts
Current draw @ 12V, 279 mA
Approvals
TUV approved to UL 916 Standard
RoHS Compliant
FCC Part 15 Compliant
DNP compliant
OPC self-tested to conformance
CE Mark
BTL Mark
TUV approved to UL 916 Standard
RoHS Compliant
FCC Part 15 Compliant
DNP compliant
OPC self-tested to conformance
LonMark Certification
SPID: 80:00:95:46:00:84:04:01
Profiles:
0000 - Node object (1)
0001 - Open Loop Sensor Object (5)
0003 - Open Loop Actuator Object (5)
Surge Suppression
EN61000-4-2 ESD EN61000-4-3 EMC EN61000-4-4 EFT
Physical Dimensions(excluding the external power supply)
(WxDxH):
5.05 x 2.91 x 1.6 in. (12.82 x 7.39 x 4.06 cm) excluding mounting tabs
Weight:
0.4 lbs (0.2 Kg)
Environment:
Operating Temperature:
-40°C to 75°C (-40°F to167°F)
Humidity:
5 - 90% RH (non-condensing)
“This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
 This device may not cause harmful interference
 This device must accept any interference received, including interference that may cause undesired
operation.
2
Specifications subject to change without notice
3
XXXX at the end of the part number identifies the code for the specific drivers included in the QuickServer. Refer to Appendix D.4
