4 Installation - Option: Angular Brackets
4.4.2 Optionl: Angular Brackets
Angular shaped mounting brackets for attaching the light curtain to already existing
holders, or if there is not enough space for the installation at the back
fig 20/4 angular brackets
fig 20/1 angular mounting brackets mounted at the light curtain.
fig 20/2 angular brackets
fig 20/3
FIESSLER
E L E K T R O N I K
50
ø 7
110
30
11
50
5
32
FIESSLER
E L E K T R O N I K
Fixing possiblities for
swivable fastening an-
gle Sick Typ FGS
FIESSLER
E L E K T R O N I K
20
