Fimar FME/4 - Control Descriptions (Electric)

- 11 - English language
EN
PIZZA OVENS
(ELECTRICALLY POWERED)
A) Control pane: it is equipped with the control devices needed to operate the appliance
(see "Control descriptions").
B) Oven door: it is equipped with an inspection window made of Pirex (for model FME -
FML - FMD - FYE - FYL only)
C) Processing chamber: it is equipped with a cook plate made of refractory material and
electrical resistances.
TECHNICAL SPECIFICATIONS
Table 1: Technical appliance specifications FME
Description
Unit of
measure
FME/4 FME/4+4 FME/6 FME/6+6
Power kW 4,2 8,4 7,2 14,4
Power supply V/Ph/Hz 230V/1N/50-60Hz - 230-400V/3-3N/50-60Hz
Working temperature °C 50÷500
Processing chamber
dimensions
mm 610x610x140
610x610x140
(x2)
610x910x140
610x910x140
(x2)
Appliance dimensions mm 900x735x420 900x735x750 900x1020x420 900x1020x750
Packaging dimensions mm 1000x960x570 1000x960x920 1210x960x570 1210x960x920
Net weight kg 66 114 85 150
Description
Unit of
measure
FMEW/6 FMEW/6+6 FME/9 FME/9+9
Power kW 6,4 12,8 9,6 19,2
Power supply V/Ph/Hz
230V/1N/50-60Hz - 230-400V/3-3N/50-60Hz
400V/3N/50-60Hz
400V/3N/50-
60Hz
Working temperature °C 50÷500
Processing chamber
dimensions
mm 910x610x140
910x610x140
(x2)
910x910x140
910x910x140
(x2)
Appliance dimensions mm 1150x735x420 1150x735x750 1150x1020x420 1150x1020x750
Packaging dimensions mm 1250x960x570 1250x960x920 1210x1210x570 1210x1210x920
Net weight kg 100 185 115 200
Table 2: Technical appliance specifications FML
Description
Unit of
measure
FML/4 FML/4+4 FML/6 FML/6+6
Power kW 6 12 9 18
Power supply V/Ph/Hz 230V/1N/50-60Hz - 230-400V/3-3N/50-60Hz
Working temperature °C 50÷500
Processing chamber
dimensions
mm 720x720x140 720x720x140 720x1080x140
720x1080x140
(x2)
Appliance dimensions mm 1010x850x420 1010x850x750 1010x1210x420 1010x1210x750
Packaging dimensions mm 1090x1040x570 1090x1040x920 1090x1400x570 1090x1400x920
Net weight kg 86 146 116 200
