5.3 Sensor Array Set Up
Figure 1
No
Description
No
Description
1
Wind Vane (measures wind
direction)
7
Thermo-hygrometer Sensor
(measures temperature and
humidity)
2
Wind Speed Sensor (measures
wind speed)
8
UV Sensor
3
Solar collector
9
Solar Radiation Sensor
4
Alkaline battery compartment
10
Rain Collector (self emptying)
5
LED transmission indicator (turns
on for 4 seconds on power up,
flashes once per 16 seconds)
11
Bubble Level
6
Reset button
