SPECIFICATIONS
Input Power: 7V DC or Micro USB input.
Standby Current: About 280mA (LS-20E), 320mA (LS-20EG)
RF : (Follows local regulations, other frequencies as requested)
Receiving Frequency: 915MHz (For FCC), 868MHz (For CE), 433MHz.
Transmission Frequency: 433MHz
Data Modulation: OOK (On Off Key).
Power: less than 10mW.
Range: about 100m to 300m or more @open field, 25℃ (Depends on sensors and Hardware version).
Receiver Type: super heterodyne.
RF Security Code: 16,777,216 combinations with check sum for each type of sensors.
More than 4 billion combinations in total.
Communication Link: Ethernet, wifi (Option), GSM (Option), GPRS (Option).
Event Log: max. 512 records.
Display: 4 LEDs (Away/Home/Disarm/Data).
Sensor Zones: total 288 zones. (Burglar zones x 128, Fire zones x 64, Controller zones x 32,
Medical zones x 32, Special sensor zones x 32)
Power: NiMH rechargeable battery, back-up time 6~16 hours depends on battery capacity.
Delay Activation Time: 0- 255 seconds programmable.
Digital Interfaces : micro USB socket.
Internet Interface: RJ45, wifi (Option), GPRS (Option).
Automation Switch control: RJ11 6-pin
Control of 16 units X-10 switches or (XRM-01) Relay Modules.
Wireless Socket: SW#1~SW#8.
Internal siren for Alarm warning.
Internet CMS protocol: Proprietary Scientech Protocol (ST-I, ST-II), CSV and SIA ADM-CID (2007) IP
Alarm protocol.
Wire Sensor Input: x3 can be assigned as Panic, Burglar, Fire, Medical, Tamper or Controller.
Alarm Out: Open collector transistor output with 10 Ohm protection resistor, for 5V external siren or
other alarm device, 300mA max.
Clock Accuracy: within 5 seconds daily.
Operation Temp.: -10℃~40℃.
Storage Temp.: -20℃~55℃.
Humidity: 10-95%RH.
Size: 203x120x48 mm. (Main body)
Weight: about 550 g. (Main body)
(The manufacturer reserves the right to change the specifications without prior notice)
