The light intensity can be used because the light of head and target is balanced by
an optical shutter. For further information, refer to the operating instructions (see
below).
3.3.3 Generation And Connection Of Vacuum And Compressed Air
The built in vacuum pump operates permanently as soon as the Placer Control Box is
switched on. It supplies the placer and the pipette alternately.
In the case of placement only, the hose connector of the pivot arm is directly
connected to the socket HEAD VACUUM OUT of the Placer Control Box. In the case
of thermo compression, HEAD VACUUM OUT is connected to the Control Box of the
Heated Pick-and-Place Tool using a supplied hose. The pipette is always connected to
the plug PIPETTE.
The compressed air, necessary for the positioning table, is provided at the TABLE AIR
OUT connector.
3.3.4 Placer Support
The locking electromagnet holding the positioning table and the optional Target
Finder are connected to the SUB-D socket of the Placer Control Box via a 25-pin plug.
The Target Finder is switched on as long as the foot switch is pressed to move the
positioning table while the pivot arm is in its upright position.
The electrical cable of the pivot arm is directly connected to the socket PIVOT ARM.
The foot switch for coarse positioning is connected to the socket TABLE FOOT
SWITCH. An additional foot switch, used for controlling the pipette, may be
connected to the PIPETTE FOOT SWITCH plug. For further information, refer to the
operating instructions (see below).
3.3.5 Camera Control and Power Supply For Options
The 12 V camera power supplies of two video modules (if existing), must be
connected to the output sockets CAMERA I and CAMERA II. They are switched on
alternately depending on the position of the pivot arm: CAMERA I is on when the
arm is in the upright position, CAMERA II is on when the arm is horizontal.
At the socket OPTION OUTPUT, 12 V DC is provided continuously for driving optional
devices with a max. current of 600 mA. This output is short protected by an
automatic recovery circuit breaker.
