finetech FINEPLACER lambda - Technical Data; Connection Description

FINEPLACER
®
lambda
Rev-Nr. 1.1
44
7 Technical Data
Survey table for general information (changes without notice, e.g. customer
specified, errors excepted):
FINEPLACER
®
Version (Model)
lambda A6, A7
Dimensions (W x L x H)
620 mm x 420 mm

x 700 mm

Total Weight (about)

140 kg
Range of bond force modules
0,1N – 400N
Working area
190mm x 52 mm
Positioning accuracy
A6.: 1 µm
A7.: <1 µm
Power requirements (Placer only)
100/120/230/240 VAC 50/ 60 Hz
1 phase.; about 100 VA
 Base plate dimension; Placer Control Box additional
 standard height over work bench, may be higher or lower depending on
selected video module
 incl. cabling, foot switch, Placer Control Box (W x D x H = 290 x 310 x 143
mm; 10 kg) and Positioning Table
Technical Data Sheet for Placer Control Box
Connection Description
- POWER Mains Voltage In
- AUX POWER OUT Mains Voltage Out, max 10A load
- FUSE Mains Fuse, Placer Control Box
- MODULE INTERFACE RJ-45 Socket,
FMI Bus (Finetech Module Interface)
- PC RS-232 9 pin SUB-D Socket
Serial Interface to PC
- PIPETTE FOOT SWITCH 3 pin Socket
Pipette Footswitch (shutter)
- TABLE FOOT SWITCH 3 pin Socket
Table Footswitch (shutter)
- PIVOT ARM 6 pin Socket
Arm Position Switch, Arm-LED, Arm
Button
- PLACER SUPPORT 25 pin SUB-D Socket
Head and Target Lighting,
Table Magnet, Target Finder
