The configuration shown in fig. 1 allows orthogonal view of the objects
component (F) and substrate (C), so both are seen to be observed "vertically from
above" (A). The overlay image allows a comparison of all connectors on each
component lead with each substrate pad at a glance.
2.3 Method of Working, Positioning and Placement
To adjust the positioning table (29) manually, observe the dual image overlay
through the video system. Coarse align using the air cushion, fine align by means of
the micrometer screws. Angular deviations are eliminated by turning the positioning
table around an electromagnet mounted in the optical axis.
Shift the video optics to the right-hand end position and place the component held in
the positioning head (F) on the substrate (C) by simply swinging down the pivot
arm (27) following the curve (G). To release the component, switch off the
placement head's vacuum by pressing the vacuum foot switch.
FOR AN ACCURATE PLACING IT IS AN ESSENTIAL PRECONDITION,
• THAT THE TABLE HEIGHT HAS BEEN BROUGHT INTO THE WORKING LEVEL (B) WITH THE HELP
OF THE MICROMETER SCREW
(51A) AND THAT THE UPPER ARM POSITION (UAP) HAS BEEN
ADJUSTED AS DESCRIBED IN 4.2.2, SO THAT LEVEL (B) AND (E) FORM AN RIGHT ANGLE.
• THAT THE BEAM SPLITTER (30) HAS BEEN ADJUSTED CORRECTLY AS DESCRIBED IN 4.2.3.. IT
IS NOT NECESSARY TO PERFORM THE ADJUSTMENT PROCEDURE BEFORE EACH WORKING
PROCESS BUT TO CHECK IT OCCASIONALLY
.
2.4 Purpose of the Equipment; Warning Against Misuse;
Warranty Conditions
The FINEPLACER
®
equipment is intended only for industrial and skilled trade use and
must be run and serviced by qualified personnel only. Everyone must observe the
caution, circumspection, and responsibility required to run this equipment, consisting
of mechanical, optical, mains powered, electromechanical and electrical heating
appliances, and possibly using compressed air or an inert gas. Operators must not be
under the influence of alcohol or other drugs and must not allow their attention to be
distracted.
FINEPLACER
®
equipment is designed to be used solely for work on components and
substrates in the way intended in a configuration agreed with Finetech and together
with Finetech approved equipment. In other cases it must be expressly agreed in
writing with Finetech GmbH, Berlin, Germany, under the conditions stated in the
manual. Any other use, changes, use of foreign controls or procedures not laid down
in this manual may cause risks. Any single, complete FINEPLACER
®
Base Module in
proper working condition, with or without additional optional Finetech modules, is
considered to be one apparatus. Modules are not considered to be independent
