FINEPLACER
®
lambda
Rev-Nr. 1.1
- OPTION OUTPUT, CAMERA I, CAMERA II Sockets Output 12V DC,
max. 12W/outlet, max. 24W
collective load
- ILLUMINATION CONTROL 3 pin Socket
Control Voltage Cold Light
- TABLE AIR OUT Table Air Outlet
- HEAD VACUUM OUT Arm Vacuum Outlet
- PIPETTE Pipette Connector
- COMPRESSED AIR Compressed Air Input
- INPUT VACUUM (option) Connector ext. Vacuum
- Mains Voltage 230V, 240V / either 50Hz or 60 Hz *
100V, 120V / either 50Hz or 60 Hz *
(* The Placer Control Box is factory-
provided pre-adjusted internally for a
specific mains voltage in combination
with a specific frequency)
- Mains Fuse 230V, 240V: 1,25A slow
100V, 120V: 2,5A slow
- Power consumption max. 200VA
- Vacuum generation typical. -0,4bar/ -5,8psi
Alternatives:
- Vacuum generation (compressed air): 6 bar (-0,5/ +1 bar) free of water, oil
and particles
- External vacuum supply (option): General function range between -0,4
and -0,8bar **,
(**factory-provided pre-adjusted
internally for standard vacuum-
switch actuation point at -0,6bar, in
case of lower grad vacuum the
vacuum switch must be readjusted)
- TABLE AIR OUT 1bar/ 14,5psi (internal pump)
- Weight: Placer Control Box 9,3 kg, Placer Arm
max. 1kg
- Dimension: 285 x 290 x 145mm (l x w x h)
- Length Placer-Arm-Connector: ca. 1,8
Environment:
- Operating conditions: 15-35°C/ 59-95°F ambient
temperature
20-75% relative humidity
