Finn 5 Series - Feed Roll and Floor Assembly

MB50 MU0518 Rev. A
59
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
FEED ROLL AND FLOOR ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 F605-0109 Doghouse-Left Hand Side 1
2 075833 Feed Roll 1
3 F605-0110 Doghouse Cover 1
4 F605-0108 Doghouse-Right Hand Side 1
5 075317 Rear Door 1
6 F605-0124-01 Airlock Right Hand Side Baffle 1
7 F605-0066 Rear Knife Cover 1
8 F605-0111 Rear Knife Filler 1
9 075604 Rear Floor Drive Shaft 1
10 075583 Floor Chain 1
11 052224 Floor Chain Sprocket - Rear 2
12 075219 Front Take-Up Bearing Frame 2
13 075220 Front Take-Up Bearing 2
14 075606 Rear Floor Bearing 2
15 071238 Hose Reel Motor 1
16 075224 Overcenter Draw Latch 2
17 052436 Door Safety Switch 2
18 075277-03 Door Switch Mounting Angle 1
19 075792 Antenna Mounting Bracket 1
20 075277-01 Top Door Support Angle 1
21 075277-02 Bottom Door Support Angle 1
22 075825 Coupling Guard 1
23 055267-01 Feed Roll Motor Mount Plate 1
004630 Torque Arrester Rubber Tube 1
24 045031 Hose Reel Mounting Hub 1
25 052391 Feed Roll Motor 1
NOT SHOWN
F705-0018 Floor Pan 1
075822 Feed Roll Shaft 1
F605-0124-02 Airlock Left Hand Side Baffle 1
075277-05 Rear Knife Angle Bracket 1
075215-02 Front Floor Idler Shaft 1
075218 Floor Chain Sprocket - Front 2
004635 Feed Roll Mounting Bushing 1
075776 Rear Wiper Angle 1
075824 Feed Roll Bearing 1
080523 Feed Roll Motor Coupling 1
