MB50 MU0518 Rev. A
77
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
HYDRAULIC MANIFOLD
Ref. Kit No.
No. Ref. Part Number Description Req’d
1 012087 #12SAE x #12JIC Straight Fitting (Installed in Port P) 1
2 FW65225 #12SAE x #16JIC Straight Fitting (Installed in Port T) 1
3 055659 2050 psi Pressure Switch (Installed in Port PS1) 1
4 055601 #6SAE x #6JIC Straight Fitting 6
(Installed in Ports A1, A2, A3, B1, B2 AND B3)
5 075902-11 Pressure Gauge (Installed in Ports G-1 and G-2) 2
6 052336 2400 psi Pressure Switch (Installed in Ports PS2) 1
7 075902-01 Custom Machined Manifold Block 1
8 075902-02 Flow Divider Manifold Cartridge Valve (Installed in Port FD-1) 1
9 075902-03 Proportional Priority Flow Control Valve (Installed in Port PPFC-1) 1
055863 Solenoid Coil for PPFC Valve 1
055856-02 Solenoid Coil Nut for PPFC Valve 1
10 075902-04 Relief Valve (Installed in Ports RV-1 and RV-2) 2
11 075902-05 Floor Directional Control Valve (Installed in Ports DCV-1) 1
055865 Solenoid Coil with Deutsch Plug 2
055866 Solenoid Coil Nut 2
12 075902-06 Airlock Directional Control Valve (Installed in Ports DCV-2) 1
055865 Solenoid Coil with Deutsch Plug 2
055866 Solenoid Coil Nut 2
13 075902-07 Hose Reel Directional Control Valve (Installed in Ports DCV-3) 1
055865 Solenoid Coil with Deutsch Plug 1
055866 Solenoid Coil Nut 1
14 075902-08 Priority PSI Compensated Flow Control Valve 1
(Installed in Port PFC-1)
15 075902-09 Relief Valve (Installed in Ports RV-3 and RV-4) 2
16 075902-10 Priority PSI Compensated Flow Control Valve 1
(Installed in Port PFC-2)
17 075923 #2SAE Socket Head Plug 14
18 075924 #4SAE Socket Head Plug 16
KITS AND MARKERS
075902 Hydraulic Manifold Assembly
To Next Page
