WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
FLOOR DRIVE ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 023850 Grease Hose 4
008154 Grease Fitting Adapter 2
160052 90º Elbow 2
2 075223 Pillow Block Bearing 1
3 075232 1 in. Flange Bearing 2
4 075359 Idler Sprocket (1 in. Bore) 1
5 075368-02 Upper Chain Pivot Weldment 1
6 1/4 in. x 2 in. Long Key 3
7 075822 Feed Roll Shaft 1
8 075215-03 1 in. Diameter x 7 in. LG. Idler Shaft 1
9 075371 Drive Sprocket (1-1/2 in. Bore) 1
10 3/8 x 2 in. Keyway 1
11 075368-01 Lower Chain Pivot Weldment 1
12 075215-04 Dual Sprocket Idler Shaft 1
13 007705 Grease Fitting 4
14 012520 Bulkhead Fitting 4
15 F705-0051 Chain Guard Angle 1
16 075363 Feed Roll Drive Chain 1
17 F705-0031 Chain Guard Bottom Pan 1
18 075605 Large Floor Sprocket 1
19 F705-0013 Chain Guard 1
20 075360 1-1/4 in. Flange Bearing 2
21 075357 Idler Sprocket (1-1/4 in. Bore) 1
22 075358 Large Idler Sprocket 1
23 075361 Floor Drive Chain 1
NOT SHOWN
F705-0030 Bottom Chain Guard 1
F705-0032 Inner Chain Cover Plate 1
