21
LUBRICATION CHART
Ref. No. Location Lubricant Frequency Number
1 Clutch Shaft Bearing CL Weekly 1
2 Check Engine Oil Level MO Daily 1
3 Clutch Yoke Shaft CL Weekly 2
4 Check Air Cleaner Daily 1
5 Check Hydraulic Oil Level HO Daily 1
Change Hydraulic Oil and Filter HO Annually 1
6 Discharge Elbow Bearing CL Daily 1
Rotate Elbow to 6 or 8 different positions
7 Power Feed Shaft Bearings CL Weekly 4
8 Feeder Roll Bearing CL Weekly 1
9 Blower Shaft Bearings CL Weekly 2
10 Check Fuel Tank Level DF Daily 1
11 Change Engine Oil MO See Engine Manual 1
12 Check Engine Coolant Level AF Daily 1
Check Engine Coolant AF Seasonally 1
13 Check Oil Filter See Engine Manual 1
14 Repack Wheel Bearings CL Seasonally 2
15 Change Hydraulic Oil Filter HO Seasonally 1
16 Check Fuel Filter Daily 2
LUBRICANT OR FLUID USED
CL Chassis Lubricant
MO Motor Oil - See Engine Manual
AF 50/50 Anti-Freeze and Water Mixture
DF Diesel Fuel
HO Hydraulic Oil, ISO Grade 46
TIME KEY
DAILY (8 hours)
WEEKLY (40 hours)
SEASONALLY (500 hours)
ANNUALLY (2000 hours)
SEE ENGINE MANUAL
FLUID CAPACITIES
Fuel - 27 Gallons (102 L)
Hydraulic Oil - 8 Gallons (30 L)
Engine Coolant - 3.75 Gallons (14.2 L) 50/50 Mix Only
Engine Oil - 14 Quarts (13.3 L)
