49
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
FEED CHUTE ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 023542 Feed Chute Extension 1
2 023570 Feed Chute Weldment 1
3 023590 Feed Chain Guard 1
4 023361 Drive Chain Guard 1
5 023153 Drive Chain 1
6 X12112 Hinge Bolt 2
7 023171-01 Feed Chute Cover 1
8 023348-02 Air Baffle Door Rod 1
9 F260-0016 Air Baffle Door 1
10 023158-02 Bale Holder - Right Hand Side 1
11 F260-0020-01 Right Hand E-Stop Mount 1
12 023862 E-Stop and Enclosure* 2
13 023158-01 Bale Holder - Left Hand Side 1
14 F260-0020-02 Left Hand E-Stop Mount 1
15 023134 Drive Sprocket 1
16 023249 Key 1
17 023198 Drive Shaft 1
18 020386 Feed Chain Shaft Bearing 4
19 021823 Grease Fitting 1 per
20 021517-02 Sprocket With Key 1
21 023250 Key 1
22 023197 Idler Shaft 1
23 021517-01 Sprocket - Plain Without key 1
24 021516 Feed Chain 1
25 020687 Pick Chain Link A/R
26 020686 Plain Chain Link A/R
NOTE:
* See Pages 46-47 for Wiring Diagram.
