Finn B260 SEB - Engine Wiring Diagram

47
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
ENGINE WIRING DIAGRAM
Part Number Description No. Req’d
023862 E-Stop and Enclosure* 2
052436 Door Switch** 1
011851 Battery*** 1
000241 Ground Strap 1
080096 Battery Cable*** 1
007336 Amber Flashing Light**** 1
021198 Flasher 1
075522 1-1/4" Dia Loop Clamp 1
022891 Starter Relay 1
031401 Stud Type Junction Block - 8 Std 1
NOTES:
* See Pages 48-49 for Location
** See Pages 30-31 and 52-53 for Location
*** See Pages 26-27 for Location
**** See Pages 52-53 for Location
