Finn B260 SEB - Feeder Roll Assembly

51
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
FEEDER ROLL ASSEMBLY
Ref. No. Part Number Description No. Req’d
1 023189 Feeder Roll Assembly 1
2 023596 Drive Sprocket 1
3 020586 Flange Bearing 1
4 023125 Feeder Roll End Cap - Bearing Side 1
5 023123 Feeder Roll Weldment 1
6 023152 Feeder Roll End Cap - Motor Side 1
7 023249 Key 1
8 023190 Feeder Roll Drive Shaft 1
9 023250 Key 2
10 021440 Bushing 2
11 023156 Rigid Coupling 1
12 000393B Bushing 1
13 023754 Hydraulic Motor* 1
NOTE:
* See Pages 40-41 for Hydraulic System Diagram.
