53
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
OPERATOR PLATFORM
Ref. No. Part Number Description No. Req’d
1 023626 Lower Transition 1
2 023633-02 Rotary Stop 1
3 052436 Door Switch* 1
4 052707 Hex Nut 1
5 023689 Clamp 1
6 023690 Strike 1
7 023688 Access Door 1
8 007336 Amber Flashing Light* 1
9 023638-03 Hand Rail 1
10 023551 Ladder 1
11 023549 Platform 1
12 023638 Guard Rail 1
13 023836 Kick Strap Assembly 1
14 023374 Bearing Assembly 1
15 023473 Allen Wrench Pipe Plug 1
16 021823 Grease Fitting 2
17 023350 Bearing Balls 81
18 023351 O-Ring 1
19 023368 Gasket 2
20 023587-01 Elbow Stop Plate 1
21 023633-03 Gas Spring Lower Mount - Left Hand Side 1
22 023633-01 Gas Spring Lower Mount - Right Hand Side 1
23 023657 Gas Spring Assembly 2
24 023609 Gas Spring 1 per
25 023611 Safety Clip 2 per
26 023610 Ball Stud 2 per
27 023160 Gas Spring Cover 2
28 080086 Spring Nut 2
NOTE:
* See Pages 46-47 for Wiring Diagram
To Next Page
