45
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
CONTROL BOX WIRING DIAGRAM
Part Number Description No. Req’d
023868 Tier II Control Box Cable Assembly 1
FW71555 Toggle Switch 1
080526 Switch Boot 1
052076 Key Switch 1
023076 Key For Ignition Switch 1
023869 Modified Control Box 1
012739 PowerView 1
006245 Pilot Light 1
022425 Diode 1
FW71749-02 30 Amp Relay 1
012727 Throttle Control Card 1
052118 Circuit Fuse Panel 1
045056 10 Amp Blade Mount Circuit Breaker 4
006499 Horn* 1
023720 Horn Button 1
JDRE503681 Throttle Emulator
NOTES:
* See Pages 34-35 For Location.
