31
WHEN ORDERING PARTS, BE SURE TO STATE
SERIAL NUMBER OF MACHINE
SHREDDER BOX & BLOWER HOUSING
Ref. No. Part Number Description No. Req’d
1 023418 Blower Shaft End Cover 1
2 021511 Bearing 2
3 023632 Blower Cover Weldment 1
4 023311 Blower Blade Assembly 1
5 021512 Bushing 1
6 022159 Key 1
7 021361* Beater Chain Assembly - 3 Pitch 1
8 021822* Beater Chain Assembly - 4 Pitch 1
9 023228* Beater Chain Assembly - 5 Pitch 1
10 023334 Breaker Collar 3
11 021365 Blower Shaft 1
12 023752 Bearing Shield Assembly 1
13 023627 Blower Housing 1
14 023583-06 Holddown Rubber Cushion 1
15 F260-0017 Tube Holddown 1
16 023527 Holddown Strap Assembly 1
17 023794-01 Clutch Handle 1
18 004996 1" Pipe Plug 1
19 023571 Shredder Box Weldment 1
20 023574 Access Door 1
21 023572-09 Door Latch 3
22 022202 Plastic Handle Grip 3
23 052436** Door Switch 1
24 052707 Hex Nut 1
25 023536 Dust Guard 1
26 060030 Bushing 1
27 011441 Key 1
28 023595 Engine Clutch Sheave 1
29 023839 Drive Belt 1
30 060032 Blower Shaft Sheave 1
31 023649 Key 1
32 060305B Bushing 1
33 023537 Belt Guard 1
34 160052 Elbow 90 Degree ST 1/8 1
35 023850 15" Lg. Grease Hose 1
36 160152 1/8" Standard Coupling 1
37 007705 1/8" NPTF Straight Grease Fitting 1
NOTES:
* See Pages 32-33 for component breakdown.
** See Pages 46-47 for Wiring Diagram
