Cut along dotted line.
MS-9600LS Series & MS-9600UDLS Series Fire Alarm Control Panels
Operating Instructions
NORMAL - Only the GREEN AC POWER LED is on.
All other LEDs are off. LCD display will read SYSTEM ALL NORMAL.
PANEL KEY - The key to open the panel can be found at the following
location:
________________________________________________________
To return to normal after an alarm
1. Do not enter the protected area until safe to do so.
2. Clear all initiating devices. Smoke detectors will not reset if there is
still smoke in the area.
3. Reset the control panel (PRESS the RESET key).
Power failure or brownout
If AC power drops too low or fails, AC POWER indicator will go out, the
system TROUBLE LED will turn on, and the panel buzzer and any other
audible trouble devices will sound. Contact authorized service
personnel immediately. See below.
Manual activation (Fire Drill or otherwise)
Notification Appliance Circuits (NACs) can be activated by pressing and
holding the DRILL key for at least two seconds.
NOTE: You may want to disconnect the municipal box by
sliding the DISCONNECT switch, located on the 4XTMF
module, to its disconnect position (to the right). If a DACT is
connected, notify the monitoring service before conducting
any fire drills or tests.
Alarm Silencing
Notification Appliance Circuits may be silenced by pressing the ALARM
SILENCE button. The ALARM SILENCED LED will turn on.
Subsequent alarms will reactivate circuits. Press the RESET button to
clear the "silenced" condition.
NOTE: Notification Appliance Circuits may be programmed
as nonsilenceable. Also, Signal Silence Inhibit, if enabled,
will prevent silencing of NACs for one minute after an alarm
(see manual).
To test the lamps, LCD display and piezo sounder
Press and release the RESET key and check all LEDs. Every LED
should be on, LCD shows all pixels on, piezo sounder beeps.
For more information, refer to the MS-9600LS/E/C & MS-9600UDLS/E
Manual, Document #52646. It is kept in the following location:
_______________________________________________________
THIS SHEET SHALL BE FRAMED ADJACENT TO THE
CONTROL PANEL
WHEN AUDIBLE DEVICES ARE SOUNDING -
FOR AN ALARM
1. Evacuate the protected area
2. Notify the monitoring service and/or the Fire Department immediately. Tell them briefly what happened and what your current status is.
Phones: ________________________________________ _____________________________________________
Fire Department Monitoring Service
3. If the Fire Department is responding, be prepared to provide directions to arriving firefighters.
FOR TROUBLE ONLY
1. Notify the monitoring service and/or the Fire Department if this panel is connected to either one, and tell them what is happening.
2. Silence audible devices by unlocking and opening the panel and pressing the ACKNOWLEDGE/STEP key. The yellow system TROUBLE
LED will remain on. Contact authorized service personnel immediately! (See Below).
WARNING!
DO NOT ALLOW TROUBLE CONDITIONS TO REMAIN LOGGED IN THE SYSTEM. THE PROTECTION THE
SYSTEM OFFERS HAS BEEN COMPROMISED OR ELIMINATED, WHEN A TROUBLE CONDITION EXISTS.
In the event of trouble, contact the
local Fire-Lite Service Representative
Name: _____________________________________
Company: __________________________________
Address: ___________________________________
Telephone Number: __________________________
Document #52645 Rev. A 07/19/07 ECN 07-484
