MS-9600LS Series Manual — P/N 52646:B8 11/20/2015 83

Master Programming Level Programming



Edit Module Screen for Control Modules

The programmer can change a module’s existing or factory default programming by pressing 3 in

the Modules Screen. The following screen will be displayed:

A flashing cursor will appear in the position of the first asterisk to the left.

The programmer keys in the three digit module address, such as 002. When the last digit is keyed

in, if the selected address corresponds to a control module, a screen displaying information about

the control module with the selected address will be displayed as illustrated in the following:

In the preceding example:

• Normal - indicates that the module with the selected address is physically installed on the SLC

and communicating with the control panel (enabled).

• <ADJ><NOUN> - represents the adjective and noun, which have been programmed,

describing the location of the displayed device.

• Control - indicates that the selected module is a control module.

• S or * - represents Silenceable (S) or Nonsilenceable (*).

• W or * - represents Waterflow Timer Delay (W = Waterflow Timer Delay enabled, * =

Waterflow Timer Delay disabled).

• ZNNN - represents the first of five possible software zones that the module is assigned to

(NNN = the three digit zone number from 000 - 099).

• 1M002 - represents the Loop, Device type and Device address (1 = SLC Loop 1, M=Module

and 002 = Module Address 02).

To change the programming for the displayed module, press the keyboard down arrow key to view

the following Edit Control screens:

Enable/Disable Module

To Enable or Disable the control module, press the 1 key while viewing the Edit Control Screen #2.

Each press of the key will toggle the screen between Enabled Yes and Enabled No. If Enabled No

is selected, the module will not be polled by the control panel, preventing the module from activat-

ing its output devices. The control panel will indicate a system trouble condition and the Disable

LED will turn on if any devices are disabled.

MODULES

1=ADD

2=DELETE

3=EDIT

Modules Screen

EDIT MODULE

ENTER MODULE ADDRESS



Edit Module Screen

NORMAL CONTROL

SW ZNNN

1M002

Edit Control Screen #1

EDIT CONTROL

1=ENABLED YES

2=TYPE CONTROL

3=SILENCEABLE YES

Edit Control Screen #2

EDIT CONTROL

1=WALKTEST YES

2=ZONE ASSIGNMENT

00 

Edit Control Screen #3

EDIT CONTROL

1=NOUN/ADJECTIVE

2=DESCRIPTION



Edit Control Screen #4

EDIT CONTROL

1=MNS OVERRIDE NO

Edit Control Screen #5

EDIT CONTROL

1=ENABLED

2=TYPE

3=SILENCEABLE

Edit Control Screen #2
