15. Alarm Count Display
The Alarm count can be displayed by pressing the
DISABLE button with the controls locked. The
count is displayed on the general LED indicators as
a binary count starting on the General Fire LED and
going down to the PSU Fault LED. The values for
each LED illuminated can be added up to give the
total count, which can be from 0 to 1023. The count
can be reset at any time by pressing the Alarm
Count Reset button, which is only accessible when
the front cover is removed.
NOTE: The Alarm Count Reset function is only
accessible at access level 4, i.e. this function should
only be operated by persons trained and authorized
by the manufacturer either to repair the CIE
(control & indicating equipment), or to alter its
firmware, thereby changing its basic mode of
operation.
