HW_FEATURES_INTERFACE_CL_CC Camera Controls (CC1..CC4) are available on
HW_FEATURES_INTERFACE_USB
Camera can be operated via USB
The command “swfeatures” returns a combination of the following bits:
#define SW_FEATURES_READOUT_CDS 0x0001
#define SW_FEATURES_READOUT_NDR 0x0002
#define SW_FEATURES_READOUT_HDR 0x0004
#define SW_FEATURES_AGC 0x0008
#define SW_FEATURES_ADAPTATIVE_BIAS 0x0010
Camera supports standard (CDS readout)
SW_FEATURES_READOUT_HDR
The camera supports HDR readout. Note that
the feature needs to be enabled via a specific
SW_FEATURES_ADAPTATIVE_BIAS
The camera supports adaptative bias
Note 1: C-RED 3 cameras do not support Camera Link Base or NDR readout.
Note 2: grayed features are not available on C-RED 3 cameras.
Embedded HTTP server
Firmware 1.3.0 introduces the possibility to control the camera and to visualize acquired images using
a standard web server (tested on Firefox, Chrome, …)
When the camera is connected using a gigabit ethernet network, the server is able to display up to 25
frames per second in full sensor resolution (640x512).
The server allows to configure main acquisition parameters (acquisition frame rate, exposure duration,
cropping, conversion gain….). The camera state is also monitored (status, temperatures….). A console
is also available to send commands that are not directly available on the web page.
Image statistics (histogram, standard deviation) are also computed on the fly.
The HTTP server is controlled using exec httpserver start and exec httpserver stop
commands.
Once started, the http server is listening on port 8888.
For security reasons, the HTTP server requests a login/password to allow access to the camera. The
login is adminnc. The password is the current password set in the camera (can be read using the
“password” command). The password can be changed by the user.
Note: The HTTP server must be restarted after each camera reboot.
