13. Optional C-RED 3 Cooling Plate
First Light Imaging can provide a cooling plate together with a cooling system allowing to maintain
the camera’s sensor to a constant temperature.
Price for this option can be provided on request, please contact contact@first-light.fr
.
Here are the 8-steps mounting procedure:
Cooling Plate Mounting
Step 1: Unpack Staubli connectors and remove the yellow tap hood as follows:
Figure 33:
Staübli male connectors
Step 2: By the help of Teflon tape, surround several times the thread of the Staubli connector. The
Teflon must be wound in the direction of the thread (clockwise).
Figure 34:
Teflon tape
