Maintenance Instructions
Seite/Page 136 - Kaptitel/Chapter 7: Maintenance Instructions 15.2.13
7.21 Replacing the V-belt at Kubota 02/05 series
NOTE:Reprehensive procedureThe described procedure is representative for Fischer Panda generators.
The original location of the item must be taken from the generator descrip-
tion of this manual. All replacements and repairs should be done by a trained
person.
Due to the relatively high ambient temperature inside the closed sound insulation capsule (approx. 85 °C), the useful
life of the V-belt is reduced. It is possible that the plasticisers in the rubber compounds may partially lose their effec-
tiveness even after a short operating time because the air in the sound insulated capsule can be both relatively
warm and dry.
The V-belt must therefore be checked at very short time intervals. It may be necessary to replace the V-belt after
several weeks because of unfavourable conditions. A replacement interval of 250 operating hours must never be
exceeded. The V-belt should be inspected after 50 operating hours. The V-belt must be considered a wearing part.
Fig. 7.21-1: Alternator fixing screw1. Loosen the fixing screw above the alternator.
Wrench with width across flats of 12 mm.
01. Fixing screw
