Types 1098-EGR and 1098H-EGR
4
Figure 2. Operational Schematics
TYPE 61LD
A6563
TYPE 1806
A6641
TYPE 6351
TYPES 6352,
6353, 6354
6350 SERIES
INLET PRESSURE
INLET PRESSURE
OUTLET PRESSURE
OUTLET PRESSURE
LOADING PRESSURE
LOADING PRESSURE
ATMOSPHERIC PRESSURE
ATMOSPHERIC PRESSURE
