Vehicle Dimensions and Weights
Vehicle Dimensions and Weights
DIMENSIONS
A Overall length 196.8 in 4998 mm
B Overall width (including mirrors) 84.0 in 2133 mm
C Overall height 52.4 in 1330 mm
D Wheel base 124.4 in 3160 mm
E Front overhang 35.9 in 913 mm
F Rear overhang 36.4 in 925 mm
G Ground clearance 5.3 in 135 mm
H Track - Front 66.6 in 1692 mm
Track - Rear 67.0 in 1701 mm
Approach angle 11.4°
Departure angle 20.0°
Breakover angle 9.9°
