Wheels and Tires
WHEEL SPECIFICATIONS
TIRE SPECIFICATIONS
TIRE PRESSURES
Wheel type Location Size
Standard production wheels
5 Spoke, Cast Alloy
Front 8.5J x 22
Rear 9.5J x 22
Optional winter tire wheels
5 Spoke, Cast Alloy
Front 8.5J x 21
Rear 9.0J x 21
Road wheel nut torque 190 Nm 140 lbf.ft
Note: For details on where to lift the vehicle, see Raising the Vehicle
, page 7.21.
Tire type Location Size
Standard production tires
GOODYEAR EAGLE F1 SUPERCAR
Front 255/35 R22 99W
Rear 285/35 R22 102W
Optional winter tires
YOKOHAMA W* DRIVE
Front 245/40 R21
Rear 265/40 R21
Tire Recommended cold inflation pressures
Standard production tires
Front
Refer to tire information label, see Tire and
loading information label / vehicle placard,
page 8.17.
Rear
Optional winter tires
Front 40 PSI 275 kPa (2.76 bar)
Rear 36 PSI 248 kPa (2.48 bar)
Owner's Handbook - US English.book Page 5 Friday, June 22, 2012 11:28 AM
