STEERING
FRONT SUSPENSION
REAR SUSPENSION
Type Rack and pinion with electro hydraulic power
steering system and variable sensitivity.
Number of turns lock to lock 2.8
Turning circle (curb to curb) 12.45 m (40 ft 10 in)
Type Independent. Co-axial coil spring/telescopic
damper. Sway bar.
Alignment optimum 0.1°
tolerance ± 0.2°
Camber optimum -0.5° per side
0.0° side to side
tolerance ± 0.5° per side
± 0.5° side to side
Caster optimum 6.0° per side
0.0 side to side
tolerance ± 0.5° per side
± 0.7° side to side
Type Independent. Co-axial coil spring/telescopic
damper. Sway bar.
Alignment optimum 0.1°
tolerance ± 0.2°
Camber optimum -1.25° per side
0.0° side to side
tolerance ± 0.5° per side
± 0.5° side to side
Owner's Handbook - US English.book Page 7 Friday, June 22, 2012 11:28 AM
