FlashCut CNC Section 11 Appendix
51
INTERNAL CONNECTORS (ORANGE)
JP40 – INPUT AUX HEADER
2 X 8 - 2MM SPACING
GPI1
1
2
OPT-GND
GPI2
3
4
OPT-GND
GPI3
5
6
OPT-GND
GPI4
7
8
OPT-GND
GPI5
9
10
OPT-GND
GPI6
11
12
OPT-GND
GPI7
13
14
OPT-GND
GPI8
15
16
OPT-GND
JP50 – OUTPUT AUX HEADER
2 X 5 - 2MM SPACING
GPO2
1
2
GPO1
GPO4
3
4
GPO3
GPO6
5
6
GPO5
GPO8
7
8
GPO7
GND
9
10
VCC
JP53 – OUT 1&2 LOW SIDE DRIVER
1 X 6 - 2MM SPACING
+5V VCC
1
CLAMP for GP02
2
GPO2 Low Side Driver
3
GPO1 Low Side Driver
4
CLAMP for GP01
5
LOGIC GND
6
JP80 - REAR PANEL POWER
JP81 - REAR PANEL FUSE
JP82 - FRONT PANEL SWITCH
CONFIGURATION JUMPERS (BLUE)
PIN 1 OF ALL JUMPERS IS INDICATED BY
A SMALL WHITE DOT PRINTED ON THE
PCB.
JP83: DB TO USB GROUND
ALWAYS LEAVE PIN 1 JUMPED TO PIN
2, PIN3 JUMPED TO PIN 4 AND PIN 5
JUMPED TO PIN 6 UNLESS DIRECTED
OTHERWISE BY FLASHCUT TECH
SUPPORT.
JP84/JP85: INPUT POWER SELECT
SHOULD BE JUMPERED THE SAME
WAY…
1-2: INPUTS DRIVEN BY ON-BOARD
VCC
2-3: INPUTS BIASED BY VOLTAGE ON
TB40
JP86: USB GROUND
SHOULD BE JUMPED TO PULL USB
GROUND TO CHASSIS GROUND
JP87: CHASSIS GROUND
SHOULD BE JUMPED TO PULL
INTERNAL SIGNAL GROUND OF THE
SIGNAL GENERATOR TO CHASSIS
GROUND.
TERMINAL BLOCKS (GREEN)
TB40: ISOLATED INPUT POWER
VOLTAGE APPLIED HERE BIASES
INPUTS IF JP84/JP85 ARE SHORTED
PINS 2-3; DO NOT
EXCEED 5V ON THIS TERMINAL
UNLESS SPECIFICALLY ARRANGED
WITH FLASHCUT TECH SUPPORT.
TB80: SMC POWER (24V)
APPLY 24 VDC HERE TO BIAS THE
STEPPER MOTOR CONTROLLER
BOARD(S) PLUGGED INTO SLOTS
SMC1-SMC5
