38.5
33 18 14.4
32.5 12
185.3
199.7
M4 depth 4mm (4x)
28.5 21
27.5 22
Connector M12 X-coded female 8-pin
ETH/PoE
Connector A-coded male 12-pin
PWR/DIG.I/O
Connector M8 A-coded
male 4-pin RS232/485
SMA female RP
ANTENNA
RESET
MAC
Optical axis
33 18
32.5
38.5
12
14 32.8
75.2
Optical axis
5 depth 3mm
1/4-20 UNC depth 6,5mm
M4 depth 5,5mm (4x)
33 18
14 32.8
12 32.5
38.5
1/4-20 UNC depth 6,5mm
5 depth 3mm
M4 depth 5,5mm (4x)
Basic dimensions for cameras with focal length:
f= 70mm
Incl. IR Lens 6 deg
1 2 3 4 5 6 7 8 9 10
1 632 54
A
B
C
D
E
F
G
H
F
C
E
G
D
A
B
Scale
1:1
A
Rev
Modified
R&D Instruments
-
Basic dimension Axxx/GF7xa
T130771
3(3)
A2
Denomination
Drawn by
Check
Size
Drawing No.
Sheet
7
© 2016, FLIR Systems, Inc. All rights reserved worldwide. No part of this drawing may be reproduced, stored in a retrieval system, or transmitted in any form, or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without written permission from FLIR Systems, Inc. Specifications subject to change without further notice. Dimensional data is based on nominal values. Products may be subject to regional market considerations. License procedures may apply.
Product may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Diversion contrary to US law is prohibited.
2020-01-10
