Thermographic
measurement
techniques
15
15.2.1.1.1
Method
1:
Direct
method
Follow
this
procedure:
1.
Look
for
possible
reflection
sources,
considering
that
the
incident
angle
=
reflection
an-
gle
(a
=
b).
Figure
15.1
1
=
Reflection
source
2.
If
the
reflection
source
is
a
spot
source,
modify
the
source
by
obstructing
it
using
a
piece
if
cardboard.
Figure
15.2
1
=
Reflection
source
#T810252;
r
.
AA/41997/41997;
en-US
44
1.888.475.5235
info@FLIR-Dir
ect.com
F
L
I
R
-
D
I
R
E
C
T
.
c
o
m
47
49
