Technical data10
10.4 FLIR ETS320
P/N: 63950-1001
Rev.: 41898
General description
The FLIR ETS320 is FLIR’s first electronic test bench camera, designed for a quick temperature check of
PCB boards and electronic devices. The FLIR ETS320 is sensitive enough to detect subtle temperature
difference with an accuracy of ±3°C, so you can quickly find hot spots and potential points of failure. The
320 × 240 pixel infrared detector offers more than 76 000 points of temperature measurement, eliminating
the guesswork of legacy measurement tools. Designed specifically for bench-top work, the battery-pow-
ered FLIR ETS 320 connects to your PC for immediate analysis and sharing of thermal data.
Benefits:
• Reduces test times: Quickly identify hot spots, thermal gradients, and potential points of failure.
• Improves product design: Know where and when to add fans and heatsinks, and ensure products are
operating within specification for their maximum lifetime.
• Saves money: Improve rapid prototyping and reduce product development cycles.
• Optimizes lab time: Battery powered and hands-free, and offers complete measurement and analysis
in the camera.
Key features:
• >76 000 points of non-contact temperature measurement at the push of a button.
• 320 × 240 pixel detector provides crisp thermal imagery.
• Time versus temperature measurement with FLIR Tools+.
• Small-component measurement, down to 170 µm per pixel spot size.
• Lens offers a 45° thermal view of the target for the quick detection of hot spots.
• Records radiometric imagery in standard JPEG format for easier sharing.
• ±3% accuracy promotes quality assurance and factory acceptance of PCBs.
• Quickly mounts on the supplied stand for immediate use.
• Crisp 3 in. LCD display provides immediate thermal feedback.
• World-class software provided for advanced measurement corrections/capabilities.
Imaging and optical data
IR resolution 320 × 240 pixels
Thermal sensitivity/NETD <0.06°C (0.11°F)/<60 mK
Field of view (FOV)
45° × 34°
Fixed focus distance
70 mm ± 10 mm
Spatial resolution (IFOV)
2.6 mrad
F-number 1.5
Image frequency 9 Hz
Detector data
Detector type Focal plane array (FPA), uncooled microbolometer
Spectral range
7.5–13 µm
Image presentation
Display 3.0 in. 320 × 240 color LCD
Image adjustment
Automatic/manual
#T810252; r. AA/41997/41997; en-US
28
