Camera Installation
General
Weight
4.55 lb (2068 g) with sun shield
(7.5 mm, 9 mm, 13 mm, 19 mm, 25 mm, 35 mm)
5.20 lb (2364 g) with sun shield (60 mm)
5.65 lb (2568 g) with sun shield (75 mm)
Dimensions (L,W,H)
9.2" x 4.6" x 4.1" without sun shield,
(234 mm x 117 mm x 104 mm)
11.5" x 5.1" x 4.6" with sun shield,
(292 mm x 130 mm x 117 mm)
General Purpose Input/
Output (GPIO)
One input dry alarm contact;
One output relay contact (rated load 0.025 A max at 5 Vdc)
Input Voltage dc 11 Vdc to 32 Vdc
Input Voltage ac 18 Vac to 32 Vac
Input Voltage PoE+
IEEE 802.3af-2003 standard or higher power,
IEEE 802.3at-2009 standard
Power Consumption
5 W nominal at 24 Vdc
Peak at 24 Vdc: 23 W with lens heater
8 VA nominal at 24 Vac
Peak at 24 Vac: 32 VA with lens heater
Mounting Provisions
Two 1/4-20” threaded holes on top and bottom,
1" spacing along center line front to back.
Four M5 threaded holes bottom,
40 mm x 62 mm (1.6 in x 2.4 in) spacing square.
Shipping weight 6.2 lbs (2.8 kg) to 6.9 lbs (3.13 kg)
Shipping Dimensions 14.375”(L) x 7.375”(W) x 7”(H)
microSD card
Local storage of image files up to 64 GB
(supplied by customer)
Measurement
and Analysis
Analytics Features
Region Entrance/Intrusion Detection, Crossover/Fence Trespassing;
Auto/Manual Depth Setup, Human and Vehicle Rules, Hand-off target to
autonomous PTZ tracking, Tampering Detection
Analytics Management
Web-based configuration and management, Masking of analytic
detection areas, adjustable sensitivity, automatic responses, remote I/O
control
Environmental
IP rating (dust and water
ingress)
IP66 & IP67
Operating temperature range
-50 °C to 70 °C (-58 °F to 158 °F) continuous
-40 °C to 70 °C (-40 °F to 158 °F) cold start
Storage Temperature range -55 °C to 85 °C (-67 °F to 185 °F)
Humidity 0-95% relative
Shock MIL-STD-810G Method 514.6
Vibration IEC 60068-2-27, 10g shock, 11 ms half-sine profile
Approvals
FCC Part 15, Subpart B, Class A, EN 55032: 2012 (for IT Equipment),
EN 55024: 2010 (for IT Equipment), EN 50130-4: 2011 (for Alarm
Systems), IEC 62599-2: 2010 (for Alarm Systems), EN 50121-4: 2015 (for
Railway Applications - EMC)
