427-0089-00-12 Version 160 March 2019 47
This document does not contain any export-controlled information.
Advanced Configuration
The default value for the stream from VIDEO - 0 is ch0. For example, the complete connection string
is: rtsp://192.168.250.116/ch0. This stream name can be used to open a video stream with a third-
party video player. By default the video stream uses the IP address of the camera.
3.1.3 Thermal Image Setup
In most installations it will not be necessary to change the thermal camera from the default settings.
However in some situations, depending on weather, time of day and so on, it may be useful to make
changes to the video image to enhance the image by modifying one or more of the parameters. In
most situations, it will be adequate to select a different Scene Preset (described below). However, be
aware that when the conditions change the camera may need to be adjusted again; for that reason it
is a good idea to know how to restore the factory default settings as well.
IR Page
In the IR page, a single JPEG image (a snapshot) is displayed in the upper right-hand corner. To
update this image at any time, select the Refresh button in the upper right. This will cause the entire
page to refresh, including the image and all the parameter values (be patient, ti may take some
time).
To make adjustments to the thermal image, it is possible to modify the Automatic Gain Control (AGC)
settings, which are grouped under the AGC ROI and AGC headings. The overall image display (also
known as Polarity or Color Palette) is determined by the Look Up Table (LUT) selected in the Misc.
(Lookup Table) section.
