3.6JCU-2Mounting
Note:
TheJCU-2joystickcontrolunitisavailableasanoptionalaccessory(500-0398-10).
Locationrequirements
Whenplanningtheinstallationlocation,considerthefollowingpoints:
•Selectapositiononyourvesselthatisclosetoadisplayshowingthecameravideooutput.
•Ensuretheunitismountedatleast1m(39.4")awayfromanyequipmentttedwitha
magneticcompass.
•Theunitcanbemountedtoadashorothersurfaceinanyorientation.
Installation
37
