FLIR PTU-5 - G - Mechanical Drawings

Copyright 2017, FLIR Commercial Systems, Inc.
B-1
B - Mechanical Drawings
The drawings in this Appendix describes the payload mounting patterns for the different brackets and
displays the PTU dimensions.
6.18
157.0
2.56
65.0
6.03
153.2
3.76
95.6
4.90
124.5
4.37
110.9
2.68
68.0
