PTU-5 User Manual
Copyright 2017, FLIR Commercial Systems, Inc.
4
This manual also contains important safety information and instructions in specially formatted callouts
with accompanying graphic symbols:
1.6 - Model Number
Each PTU unit includes a model number that is located on the base of the unit. This number lists the
options present on that particular unit. The PTU-5 model number is 445-0005-01-00.
1.7 - PTU Package Contents
Your PTU package includes the following
items:
• PTU-5 unit
• AC/DC power supply with cord
(PT-PS-30V-NA)
• Payload mounting brackets (top or
side)
• Mating connector for payload
(Phoenix Contact #1411987)
• Breakout cable (308-0278-XX-00,
where XX is the cable length in feet);
available in various lengths
• USB to RS-485 adapter cable
• PTU-5 Series User’s Manual (this
document)
• Pan-Tilt E Series Command Reference Manual
• CD containing the PTU Finder utility and other documentation.
WARNING: CAUTIONS ALERT YOU TO THE POSSIBILITY OF PERSONAL INJURY IF THESE
INSTRUCTIONS ARE NOT FOLLOWED.
CAUTION: CAUTIONS ALERT YOU TO THE POSSIBILITY OF EQUIPMENT OR PROPERTY
DAMAGE IF THESE INSTRUCTIONS ARE NOT FOLLOWED.
Note: Notes provide helpful information.
