FLIR TermaCAM E45 User Manual

8.5 Changing level & span
8.5.1 Changing level
ActionStep
Press MENU/YES to display the vertical menu bar.1
Point to Manual adjust on the vertical menu bar and press MENU/YES.2
Press the navigation pad up/down to change the level. An arrow pointing upwards
or downwards will be displayed.
3
For more information about level, see section 10.4.3 – Manual adjust/Automatic adjust
on page 65.
8.5.2 Changing span
ActionStep
Press MENU/YES to display the vertical menu bar.1
Point to Manual adjust on the vertical menu bar and press MENU/YES.2
Press the navigation pad left/right to change the span. Two arrows pointing away
from each other or towards each other will be displayed.
3
For more information about span, see section 10.4.3 – Manual adjust/Automatic adjust
on page 65.
8
46 Publ. No. 1558439 Rev. a156 – ENGLISH (EN) – February 28, 2006
8 – Tutorials
