FLIR TermaCAM E45 User Manual

10.4.9 Setup
10383003;a4
Figure 10.14 Setup menu
10.4.9.1 Settings
10382003;a4
Figure 10.15 Settings dialog box
Figure 10.16 Explanations of the Settings dialog box
ExplanationValueLabel
■
Select On to display the scale on the screen
■
Select Off to hide the scale
■
On
■
Off
Scale
■
Select On to display the information field at the
bottom of the screen
■
Select Off to hide the information field
■
Select On + TRefl to display the information
field and the reflected ambient temperature
■
On
■
Off
■
On + TRefl
Info field
■
Select Laser to activate the laser when pulling
the trigger
■
Select Save to save the current image when
pulling the trigger
■
Select Disabled to disable the trigger
■
Select One-shot autoadjust to autoadjust the
camera when pulling the trigger
■
Laser
■
Save
■
Disabled
■
One-shot autoadjust
Trigger
■
Select Low to set the LCD intensity to the lowest
level
■
Select Medium to set the LCD intensity to
medium level
■
Select High to set the LCD intensity to the
highest level
■
Low intensity of the
LCD
■
Medium
■
High
LCD intensity
10
Publ. No. 1558439 Rev. a156 – ENGLISH (EN) – February 28, 2006 69
10 – Camera program
