10.4.5 Palette
10382603;a4
Figure 10.11 Palette dialog box
Point to Palette on the vertical menu bar and press MENU/YES to display the Palette
dialog box.
■ To select another palette, press the navigation pad left/right
■ To confirm the choice, press MENU/YES
■ To cancel any changes, press PWR/NO
10.4.6 Range (extra option)
Point to Range on the vertical menu bar and press MENU/YES to display the Range
dialog box.
■ To select another temperature range, press the navigation pad left/right
■ To confirm the choice, press MENU/YES
■ To cancel any changes, press PWR/NO
10.4.7 Hide graphics / Show graphics
Point to Hide graphics on the vertical menu bar and press MENU/YES to hide all
graphics currently displayed on the screen. To display the graphics again, either:
■ Point to Show graphics on the menu, or
■ Briefly press SEL, or
■ Briefly press MENU/YES, or
■ Briefly press PWR/NO
➲ The laser icon overrides the Hide graphics menu selection. This means that even
though Hide graphics is selected when the Laser LocatIR is lit, the laser icon will still
be displayed on the screen.
10
Publ. No. 1558439 Rev. a156 – ENGLISH (EN) – February 28, 2006 67
10 – Camera program
