FLIR TermaCAM E45 User Manual

10396303;a3
Figure 8.2 Removing a lens
ActionStep
Rotate the locking ring on the camera 30° counter-clock-wise until the index mark
is lined up with the laser window.
1
Carefully pull out the lens. Do not use excessive force.2
8.7.2 Adjusting the focus
➲ Please note what is the locking ring and what is the focus ring in figure 8.1 on page
49. Trying to adjust the focus by rotating the locking ring will remove the lens.
ActionStep
To adjust the focus, rotate the focus ring clock-wise or counter-clock-wise.1
8.7.3 Inserting & removing the battery
➲ The camera is shipped with charged batteries. To increase the battery life, the
battery should be fully discharged and charged a couple of times. You can do this
by using the camera until the battery is fully depleted.
8
50 Publ. No. 1558439 Rev. a156 – ENGLISH (EN) – February 28, 2006
8 – Tutorials

FLIR TermaCAM E45 Specifications

General

Brand	FLIR
Model	TermaCAM E45
Category	Thermographic Cameras
Language	English
