Flowserve Limitorque L120-190

To Next Page

To Previous Page

Limitorque

L120-190 through L120-2000 FCD LMENIM1203-01-A4 – 05/15

The approximate L120 actuator weights are provided below:

Table 3.1 – Actuator Weights

Actuator Size Control Types

Drive 1 Weight Side HW Drive 2 Weight Side HW

lb. kg lb. kg

L120-190

NCU

520 192 520 192

BIC

586 217 586 217

UEC/Clamshell

586 217 586 217

L120-420

NCU

1065 394 1065 394

BIC

1130 418 1130 418

UEC/Clamshell

1220 451 1220 451

L120-800 NCU

1270

471

1700

629

L120-2000 NCU

2500

925

3300

1221

Note 1: Torque Only

Note 2: Torque and Thrust

Note 3: NCU = No Controls Actuator

BIC = Basic Integral Controls

UEC = Universal Electronic Controller

Actuator Weights
