Flowserve Limitorque L120-190 - Table 7.2 - L120-2000 Typical Parts List

47
Limitorque
®
L120-190 through L120-2000 FCD LMENIM1203-01-A4 – 05/15
flowserve.com
Table 7.2 - L120-2000 typical parts list
Piece No. Quantity Description Piece No. Quantity Description
1 1 Housing 50 1 Declutch Lever Nameplate
2 1 Declutch Housing 52-1 1 Ball Bearing
3 1 Housing Cover 52-6 1 Handwheel Shaft Bearing
4 1 Worm Shaft End Cap 52-7 1 Ball Bearing
5 1 Handwheel 52-8 1 Ball Bearing
8 1 Drive Sleeve 52-9 1 Ball Bearing
9 1 Handwheel Gear 53-3 1 Spirolox Ring
11 1 Declutch Lever 53-8 1 Spirolox Ring
13 1 Worm Gear 53-9 1 Retaining Ring
14 1 Bearing Cup 54-1 1 Declutch Housing Gasket
16-1 1 Bearing Cartridge Cap 54-2 2 Worm Shaft End Cap Gasket
16-2 2 Thrust Washer 54-3 1 Quad Ring
16-3 various Belleville Spring 54-5 1 O-Ring
16-5 1 Torque Limit Sleeve 54-6 1 Oil Seal
16-8 1 Bearing Cartridge Stem 54-7 3 Housing Cover Gasket
16-10 1 Cartridge Stem Locking Nut 54-8 1 Oil Seal
17 1 Hollow Drive Shaft 54-10 1 Declutch Cap Gasket
18 1 Handwheel Shaft and Pinion 54-11 1 Declutch Cover Gasket
19-1 1 Declutch Shaft 55-1 1 Hex Head Cap Screw
19-2 1 Declutch Arm 55-2 1 Lockwasher
19-3 1 Declutch Shaft Drum 55-3 1 Welsh Plug
19-5 1 Groove Pin 55-4 1 Soc Head Set Screw
19-6 1 Roll Pin 55-5 1 Lockwasher
19-7 1 Roll Pin 55-6 1 Soc Head Set Screw
22 1 Motor Adapter 55-7 1 Lockwasher
30-1 1 Worm 55-8 1 Soc Head Set Screw
30-2 1 Worm Bushing 55-9 1 Lockwasher
31-1 1 Motor Pinion 55-10 1 Jam Nut
31-2 1 Intermediate Gear 55-11 1 Flat Head Mach Screw
32-1 1 Intermediate Pinion 55-12 1 Soc Head Set Screw
32-2 1 Output Worm Shaft Gear 55-14 1 Lockwasher
33 1 Sliding Gear Clutch 55-15 1 Drive Screw
34-A 1 Clutch Tripper 56-5 1 Grease Fitting
34-B 1 Clutch Tripper 56-7 1 Key
36 1 Worm Gear Spacer 56-8 1 Hallowel Collar
37 1 Shim Set Bearing 56-9 1 Soc Head Set Screw
40 1 Bearing Cup 56-10 1 Lockwasher
41 1 Bearing Cone 56-12 1 Soc Head Set Screw
42-1 1 Declutch Fork 56-13 2 Tripper Bolt
42-4 1 Fork Roller 56-15 1 Key
42-5 1 Roller Pinion 56-16 1 Key
44-1 1 Bearing Locknut 56-17 1 Soc Head Set Screw
46 1 Clutch Compression Spring 56-20 1 Soc Head Set Screw
49 1 Spring Washer 56-21 1 Soc Head Set Screw
