Limitorque
®
L120-190 through L120-2000 FCD LMENIM1203-01-A4 – 05/15
48
Table 7.2 Continued - L120-2000 typical parts list
Piece No. Quantity Description Piece No. Quantity Description
58 1 Tripper Spring 102 1 Gear Insert
70 1 Hinge 103 1 Split Ring
70-1 1 Hex Head Cap Screw 104 1 Retaining Ring
70-2 1 Lockwasher 105 1 Motor Adaptor Gasket
73 2 Bearing Cup 106 1 Hex Head Cap Screw
76 1 Gear Limit Threaded Collar 107 1 Lockwasher
77 1 Solid Drive Shaft 114 1 Hex Head Cap Screw
78 1 Gear Clutch Spacer 122 1 Thrust Drive Sleeve
79 1 Bearing Adapter 125 1 Thrust Adapter Housing
80-1 1 Bearing Locknut 126 1 Thrust Drive Sleeve
81-1 1 Bearing Locknut 127 1 Stem Nut
81-2 1 Bearing Locknut 128 1 Bearing Cartridge
82-1 1 Flexible Jaw Clutch Housing 129 1 Seal Retainer Plate
82-2 1 Motor Clutch Gear Cam Pin 130 1 Drive Sleeve Locknut
82-3 1 Flexible Jaw Clutch Sleeve 131 1 Bearing Roller Assembly
82-4 1 Nylon Insert 132 1 Oil Seal
82-5 1 Nylon Insert 133 1 Grease Fitting
82-6 6 Clutch Sleeve Insert 134 1 O-Ring
82-7 1 Flexible Jaw Clutch Collar 135 1 Housing Thrust Adapter Gasket
83 1 Handwheel Clutch 136 1 Hex Head Cap Screw
84 1 Gear Mounting Bracket 137 1 Lockwasher
85 1 Handwheel Gear Bushing 138 1 Soc Head Set Screw
86 1 Declutch Housing Cover 139 1 Soc Head Set Screw
87 1 Splined Insert 140 1 Seal Retainer Sleeve
88 1 Handwheel Washer 141 1 Lockwasher
89 1 Handwheel Gear Spacer 162 1 Motor Adapter Gasket
90 1 Stop Stud 182 1 Handwheel Spinner Kit
91 3 Declutch Shaft Washer 200-1 1 Limit Switch Compartment Cover
92 1 Declutch Shaft Spacer 200-2 1 Hex Head Cap Screw
93 1 Declutch Lever Stop 200-3 1 Lockwasher
94 1 Torsion Spring 301 1 Torque Switch
95 1 Declutch Cap 305 1 Geared Limit Switch
101 1 Bearing Spacer
